AHB 50 • Profile Bender • Ring Roller • Hydraulic Dual Pinch • 50mm Shafts • NC Touchscreen
Product Code: ABH-50The AHB-50 Profile Bender Ring Roller is a versatile and robust machine designed for precision bending of metal profiles and rings. With its 50mm shaft diameter, high-quality Delta touch screen HMI, and three driven rolls, the AHB-50 is ideal for various industrial applications. Built with a heavy-duty SR355 steel framework, this hydraulic profile bender ensures reliable performance and long-lasting durability.
- Description
- Additional Info
The AHB-50 Profile Bender Ring Roller is a high-performance machine engineered for the precise bending of metal profiles and rings. Featuring a 50mm shaft diameter and a top roll diameter of 157mm, the AHB-50 is powered by a 1.1 kW motor and operates at 400V/50Hz. The machine’s three driven rolls and bottom moveable rolls enhance its versatility, allowing it to handle a wide range of bending tasks. The Delta touch screen HMI provides intuitive control, while the heavy-duty SR355 steel framework ensures robust construction and longevity. Suitable for various industrial applications, the AHB-50 is a reliable and efficient solution for your bending needs.
Technical Specifications:
- Shaft Diameter: 50mm
- Top Roll Diameter: 157mm
- Motor Power: 1.1 kW
- Working Speed: 2.95 mm/min
- Machine Dimensions: 1000mm (L) x 950mm (W) x 1450mm (H)
- Weight: 500 kg
- Moveable Rolls: 2
- Moveable Roll(s) Position: Bottom
- Voltage: 400V
- Frequency: 50Hz
Features and Uses:
- High-quality Delta touch screen HMI for intuitive control
- Three driven rolls for enhanced bending capability
- Bottom moveable rolls for increased versatility
- Heavy-duty SR355 steel framework for durability
- Precision bending of various metal profiles and rings
- Suitable for industrial applications requiring high accuracy and reliability
- Emergency stop and speed control for safe operation
Industries and Their Uses:
- Construction: Bending metal profiles for handrails, safety rails, and structural components.
- Automotive: Fabricating roll cages, chassis components, and custom metal parts.
- Marine: Building boat pulpits, ship structures, and marine framework.
- Art and Design: Creating metal sculptures, decorative elements, and architectural features.
- Industrial Sites: Manufacturing safety barriers, machinery guards, and framework.
- Transportation: Producing components for rail transport, bridges, and airplane frameworks.
| Profile | Dimensions [mm] | Min. Bending Diameter [mm] |
|---|---|---|
| Equal Angle Leg Out |
50 x 5 | 1000 |
| Equal Angle Leg In |
50 x 5 | 1200 |
| T-Section Leg Out |
50 | 600 |
| T-Section Leg In |
50 | 600 |
| Flat Bar Hard Way |
50 | 600 |
| Flat Bar Easy Way |
50 x 15 | 1000 |
| Flat Bar Easy Way |
80 x 16 | 1200 |
| Solid Bar | 35 x 35 | 1400 |
| Solid Bar | 40 | 800 |
| Round Tube | 70 x 2 | 1600 |
| Rectangle Tube Hard Way |
60.3 x 3.2 | 1000 |
| Rectangle Tube Easy Way |
80 x 30 x 3 | 4000 |
| U Channel Leg Out |
60 x 60 x 3 | 4000 |
| U Channel Leg In |
880 | 800 |
| T-Section Leg Up |
1000 | 1000 |
Profile Bender Capacity Chart
