Bandsaw SN 300 MRM • Manual • 220mm Round Capacity • Dual-Mitre • 3-Phase

Product Code: 7.193.04.74

Description

A Pedrazzoli Automated Cutting Line implements centralized adjustments and remote loading systems along with a gear-driven cutting head and a vertically controlled descent axis. The Metal Cutting Saw Blade speed is controlled by an inverter and the clamping vice is also a controlled axis. Cutting length accuracy is ensured by the implementation of a bar stop using a digital position readout.

CE Certified and 2 YEARS Warranty

This saw is CE Certified. All sales and services are UK based from our location in Warwickshire.

Please contact for prices

    Download Specification Sheet
    • Description
    • Additional Info

    Cutting Capacities
    Round Tubes (Diameter)

    • 45°: [mm] 160
    • 0°: [mm] 220
    • 45°: [mm] 45
    • 60°: [mm] 130

    Square Profiles (Length x Width)

    • 45°: [mm] 120 x 120
    • 0°: [mm] 290 x 290
    • 45°: [mm] 150 x 150
    • 60°: [mm] 110 x 110

    Rectangle Profiles (Length x Width)

    • 45°: [mm] 160 x 130
    • 0°: [mm] 330 x 150
    • 45°: [mm] 160 x 130
    • 60°: [mm] 110 x 110

    Technical Specifications

    • Motor [kW]: 1.25/1.75
    • Blade Speeds [mpm]: 35 / 70
    • Rotation (Left and Right) [degrees]: 45 / 60
    • Degree Interlocks(Left and Right) [degrees]:
      45 /45 and 60
    • Vice Maximum Opening [mm]: 360
    • Clamping: Manual
    • Blade Dimensions (L x T x H) [mm]: 2825 x 27 x 0.9
    • Power Requirements: 400V, 50 Hz, 3-Phase
    • Weight [Kg]: 430
    • Table Height [mm]: 950
    • Dimensions (L x W x H) [mm]: 1400 x 1500 x 1800

    Features

    • Motor Vertical Mount: Yes
    • Quick Action Clamp: Yes
    • Gear Ratio: 1:40
    • Rotation Mechanism: Ball Track
    • Blade Tensioning Device: Yes
    • Blade Guides: Bearing and Pads
    • Lubrication: Front and Back
    • Bow Descent/Retraction Mode: Gravity/Manual
    • CE Certified: Yes
    • Warranty: 2 Year

    Accessories

    • Micromist Lubrication: •
    • MRP Pneumatic Quick Clamp Kit •
    • Laser Cutting Inidicator •
    • Mechanical Speed Variator •
    • Loading & Unloading Tables •

    Bandsaws

    Metal Band Saws or Bandsaws are a critical component of all manufacturing facilities, machine shops, workshops, maintenance shops, precision engineering facilities, and more.  Bandsaws can be used to cut a wide variety of materials such as wood and meat but WorkshopPress.co.uk only offers the best quality saws designed for industrial metal-cutting.  Some primary examples of uses of a band saw are for cutting to size structural steel, bar stock, tubes, pipes, and RSJ material, and beams and they can cut bundles and complicated profiles and shapes.  Many engineers will saw a band saw is not as accurate as a circular saw but for 98% of the applications in fabrication and manufacturing a band saw provides more than sufficient accuracy during the cutting process and the accuracy is facilitated by the top quality design and build quality offered with the band saws in WorkshopPress.co.uk bandsaws.

    CE Certified with a 2-year warranty.

    All Scantool Bandsaws are Manufactured according to CE regulations and come with a 2-Year Warranty supported by WorksshopPress.co.uk technical sales and service from Warwickshire.
